P5 outdoor street lamp pole double side led display screen
Key Benefits
1. Broad viewing angle;
2. Frame-free installation;
3. Front and rear side maintenance.
4. High brightness, visible even with direct sunshine;
5. High waterproof and dustproof, IP65 both front and rear side
6. Having good lightening accordance and no mosaic;
7. Having large viewing angle: Getting vivid effect within any position of the viewing range;
8. Any LED in died pixel can be respectively repaired, which reduce the cost of the display maintenance.
LED DISPLAY, LED STADIUM SCREEN, LED OUTDOOR SCREEN, OUTDOOR BILLBOARD
Key Benefits
1. Broad viewing angle;
2. Frame-free installation;
3. Front and rear side maintenance.
4. High brightness, visible even with direct sunshine;
5. High waterproof and dustproof, IP65 both front and rear side
6. Having good lightening accordance and no mosaic;
7. Having large viewing angle: Getting vivid effect within any position of the viewing range;
8. Any LED in died pixel can be respectively repaired, which reduce the cost of the display maintenance.
LED DISPLAY, LED STADIUM SCREEN, LED OUTDOOR SCREEN, OUTDOOR BILLBOARD
| Model | PH5 |
| Pixel Pitch | 5mm |
| Unit Size | 1280mm x 1600mm |
| LED Type | 1R1G1B |
| Pixel / Unit | 256x320 |
| Unit Weight | 120kg(steel) or 90kg(Aluminum) |
| Viewing Angle | H140° V140° |
| Application | Storage-40~60° C, Working-20~50° C |
| Protection Level | IP65 |
| Power Consumption | 700W/sq.m Max |
| 350W/sq.m Ave. | |
| Driving | 1/8 |
| Frame Refresh | ≥60Hz |
| Data Refresh Rate | 1200~4000Hz |
| Processing | 16bit |
| Max Brightness | 6,500-7000nits |
| Power Supply | AC90-240V, 50~60Hz |
| MTBF | ≥1000 Hours |
| Life Span | ≥100000 Hours |
| Pixel Failure | < 0.0003 |
